| Model | GT-I310B | ||||
| Performance | |||||
| Symbologies | 1-dimensional codes: Code 39, Code 93, Code 128, CodaBar, EAN 8, EAN 13, ITF 14, ITF 25, UPCA, UPCE | ||||
| 2-dimensional codes: QR Code, Data Matrix | |||||
| Min. accuracy | 3 mil | ||||
| Max. frame rate | 50 fps | ||||
| Sensor type | CMOS, global shutter | ||||
| Pixel size | 3 μmx3 μm | ||||
| Sensor size | 1/4" | ||||
| Resolution | 1280*800 | ||||
| Depth of fieId• | Code 39 (3 mil): 15 mm to 60 mm, Code 39 (5 mil): 5 mm to 80 mm, Data Matrix (5 mil): 10 mm to 70 mm, Data Matrix (10 mil): 0 mm to 110 mm, QR Code (5 mil): 10 mm to 70 mm | ||||
| Field of view | Horizontal 31º, vertical 20º | ||||
| Detection angle | Tilt angie 1 60º, skew angie 1 60 º, rotation angle 360º | ||||
| Symbol contrast | 20％ | ||||
| Wireless communication | |||||
| Bluetooth | BT S.0, 2.4 GHz to 2.4835 GHz, BLE | ||||
| Wireless range | 100 m (open range) | ||||
| Electrical feature | |||||
| Battery | 3150 mAh, lithium battery | ||||
| Charging time | Adapter charging: 4 h, USB charging: 8 h | ||||
| Number of scan | 26000 times (full charging) | ||||
| Power supply | 3.8 VDC (battery provides power) | ||||
| Mechanical | |||||
| Focal length | 6.7 mm | ||||
| Lens mount | M5.8-mount | ||||
| Ambient illumination | 0 lux to 100000 lux | ||||
| Light source | Direct: white LED; diffused reflection: red LED | ||||
| Aiming system | Cross laser aiming | ||||
| Prompt | LED indicator, buzzer, vibrator | ||||
| Dimension | 73.4 mm | 104 mm | 215.2 mm (2.9” | 4.1" | 8.5") |
| Weight | Approx. 410 g {0.9 lb.) | ||||
| Ingress protemion | IP65 | ||||
| Temperature | Working temperature: -20 °C to 50 °C (-4 °F to 122 °F), storage temperature: 30 °C to 60 °C (-22 °F to 140 °F), charging temperature: 0 °C to 4S °C (32 °F to 113 °F) | ||||
| Humidity | 20a to 95% RH, non-condensing | ||||
| Drop height | 1.8 m (70.9") | ||||
| Solutions FAQ | |||||||||
| Q：Can not turn on or turn off immediately after turning on | |||||||||
| A：This situation is mostly caused by insufficient battery power, please charge in time to ensure sufficient power (the red light is on when charging, and the red light is off when fully charged) | |||||||||
| Q：Barcode data is not uploaded | |||||||||
| A：The scanner and receiver are not successfully matched, please match the machine according to the instructions; maybe the distance between the scanner and the receiver is far, please set it to inventory mode in advance (the barcode will be automatically uploaded within the acceptance range) | |||||||||
| Q：There is a laser line, but can't read the bar code. | |||||||||
| A：Maybe the barcode system is not turned on, follow the instructions to open it; try other barcodes to confirm whether the barcode has been damaged; it is also possible that the scanning angle is irregular,please adjust it according to the manual. | |||||||||
| Q：The scanned data is displayed incorrectly on the host | |||||||||
| A：Maybe the input method is wrong, please convert the input method to standard English or you can reset the barcode scanner, or contact the manufacturer's service center. | |||||||||
| Q：Other cases cannot be decoded | |||||||||
| A：It may be an error in the switching device, turn off the power of the device and connect the device and the scanner correctly, then turn on the power of the device, reset the scanner to the factory default state and scan the barcode again. |
